設備用途：適用于光伏玻璃背板絲網印刷工藝。

Equipment use: Suitable for photovoltaic glass backplane screen printing process.

特點：

1. 上片、精準定位、印刷，卸片全自動運行，易于操作，保證品質。

2. 精定位采用伺服電機中心定位，配合高精度直線導軌，精度高。

3. 印刷采用伺服電機，精度高確保印刷產品質量穩定，印刷物均勻無波浪狀。

4. 玻璃搬運到印刷平臺，采用伺服電機梭子穿梭式結構，速度快精度高。

5. 網版升降采用 SEW 品牌電機，上下移動，精度高穩定性好。

6. 控制系統采用進口 PLC 可編寫控制系統和人機界面。

7. 本機設有自動報警裝置及周邊安全保護開關，并可選擇配置氣動機械安全保護裝置，確保安全生產。

Features:

1. Loading, accurate positioning, printing, unloading automatic operation, easy to operate, to ensure quality.

2. Precise positioning using servo motor center positioning, with high precision linear guide rail, high precision.

3. The printing adopts servo motor with high precision to ensure stable quality of printed products and uniform printing without waves.

4. The glass is transported to the printing platform, and the servo motor shuttle structure is adopted, with high speed and high precision.

5. Screen plate lifting adopts SEW brand motor, moving up and down, high precision and good stability.

6. The control system adopts imported PLC to write the control system and human-machine interface.

7. The machine is equipped with automatic alarm device and peripheral safety protection switch, and can optionally configure pneumatic  mechanical safety protection device to ensure safe production.
